ACADP-20 AC ADAPTER with AC power cable (CE) for GL series

AC adapter that is supplied as a standard accessory.
Input supply: 100 to 240 VAC, 50/60 Hz

B-513 Logic/Alarm Cable

The Input/output cable for GL data logger enables 4 channels of
logic/pulse input, external trigger input, and alarm signal output.

Typical applications: RPM measurements, counts

B-530 Humidity sensor (3m)

• Allowable temperature range: -25 to +80°C
• Allowable humidity range: 0 to 100% RH
• Relative humidity measurement accuracy: ±3% RH (5 to 98% RH at 25°C)
• Method: Capacitance method
• Response time: 15 sec. (90% response when membrane filter is installed)
• Cable length 3 m
• Sensor power source: DC +5 to +16 V
• Power consumption approx. 4 mA

B-569 Battery pack

• • Capacity: 7.2V/2900mAh
  • Battery type: Lithium secondary battery

  When LCD is ON

  • • Battery pack x 1 (brightness MAX): approx. 3 hours
    • Battery pack x 2 (brightness MIN): approx. 6 hours

  When LCD is OFF

  • Battery pack x 1: approx. 5 hours
  • Battery pack x 2: approx. 10 hours
  • Charging method Mount in the main unit
  • Time required for charging
    • Battery pack x 1: approx. 5 hours
    • Battery pack x 2: approx. 10 hours
  • The power supply will be switched automatically to the battery in the event of a power failure.
  • The AC adapter is the primary power source.
  • Operation environment Running on battery: 0 to 40°C,
  • Battery being charged: 15 to 35°C

B-514 DC power cable (2m)

GL 240 can be powered on using DC power: 8.5 to 26.4 VDC range.
DC drive cable is an optional item and is used when operating a logger with DC power.
